SOUTH SDE-28S+ Single Frequency Digital Echo Sounder

Deskripsi

SOUTH SDE-28S+ Single Frequency Digital Echo Sounder

The SOUTH SDE-28S+ Single Frequency Digital Echo Sounder is a high-precision hydrographic survey instrument designed for measuring water depth with single-frequency sonar technology. It is widely used in hydrographic surveys, dredging operations, and underwater mapping.



Features

Single-Frequency Operation

• Operates on a single frequency, typically in the range of 200 kHz, which is suitable for most shallow to medium-depth water surveys.

High Accuracy

• Provides precise depth measurements with high resolution, ensuring reliable data for hydrographic surveys.

Depth Measurement Range

• Capable of measuring depths from 0.3 meters to over 200 meters, depending on water conditions and transducer configuration.

Real-Time Data Display

• Features a clear LCD display for real-time depth readings and graphical representation of the seabed profile.

Data Recording and Export

• Equipped with internal memory for storing survey data.
• Supports data export via USB or other interfaces for further analysis and processing.

User-Friendly Interface

• Intuitive controls and menu system for easy operation, even in challenging environments.

Durability

• Designed to withstand harsh marine environments, including resistance to water, dust, and vibrations.

Transducer Options

• Compatible with various transducers, allowing customization based on specific survey requirements.

Applications

• Hydrographic surveying
• Dredging operations
• River and lake depth measurement
• Underwater pipeline and cable inspection
• Port and harbor construction



Specifications

Measurements
Frequency	200 kHz
Beam Angle	7
Depth Resolution	0.1ft/0.01m
Accuracy	±1cm±0.1D (0.1% of depth value)
Ping Rate	14Hz, Maximum 30Hz
Sound Velocity	1300 ~ 1700m/s, resolution is 1m/s
Depth Range	0.3 ~ 600m/1800ft
Draft	0 ~ 9.9m
Gain Control	AGC and TVG, depth and gain, a double door tracking
Output Data Format	SOUTH, SDH-13D, DES025, INN455, ODOM etc
Physical
Environmental	-30 ~+60 non-condensing
Output Power	Up to 300 watts
Power Supply	9 ~ 15V DC, less than 25w, 110 ~ 265V AC (optional),
Dimension	35cm x 29cm x 14cm
Weight	7.5kg
Hardware Part
Embedded System Index	CPU frequency 1.6GHz Internal memory 2G Memory capacity 8G high-speed CF card (supports extended storage)
I/O Interface	2 USB 2 RS232 1 VGA interface
Display Panel Layout	12.1-inch color LCD Touch screen Embedded windows XP OS Power ON/OFF Interface protection Separate Panel Overlay for Keyboard Mouse
Standard Configuration	1. Echo Sounder SDE-28S+ (1pc) 2. Carrying Case (1pc) 3. Transducer (1pc) 4. Transducer Pole (1pc) 5. Carrying Case for Transducer (1pc) 6. Double RS-232 Communication Cable (1pc) 7. 220V External Power Supply Cable (1pc) 8. 220V External Power Supply Cable Adapter (1pc) 9. 12V External Power Supply Transfer Cable (1pc) 10. Keyboard (USB) (1pc) 11. Mouse (USB) (1pc) 12. USB Disk (1pc)

Remarks: Measurement accuracy and operation range might vary due to atmospheric conditions, signal multipath, obstructions, observation time, temperature, signal geometry and number of tracked satellites. Specifications subject to change without prior notice.



Datasheet
