NISSEI RS-502 SWR / Watt Meter

INTRODUCTION
This SWR/Watt meter is a highly accurate RF meter for measuring Forward Power, Reversed Power, and VSWR.

MAIN FEATURES

  • Large meter display for ease of reading.
  • Forward RF power readings. Switchable to indiecate either average power of peak Envelope
  • Power(REP) for SSB and AM transmitters.
  • Reflected RF Power readings.
  • VSWR ratios.
  • Illuminated meter.
  • Convenient control layout for easy operation.
SKU: RS-502 Kategori: Tag: , , , ,

Deskripsi

SPECIFICATIONS

MODEL RS-101 RS-102 RS-402 RS-502
Frequency Range 1.6 – 60 MHz 1.8 – 200 MHz 125 – 525 MHz 1.8 – 525 MHz
Power Range 1-3KW 1 – 200W
Power Scale 30/300/3KW 5/20/200W
Maximum Power 3KW 200W
Accuracy 5W Range

(AVG)+/-10%
(REP)+/-15%
Accuracy 20-3KW Range

(AVG)+/-5%
(REP)+/-10%
Minimum Power for SWR 3W
Input/Output Connectors M type(SO-239) M or N type
Weight (Net) 780 g 790 g 800 g 950 g
Insertion Loss Less than 0.1 dB
Testing Function FWD/REF POWER, REP, SWR
Input/Output Impedance 50 OHM
Dimension (W/H/D) 90 x 85 x135 mm
Accessories Operation Manual, 13.8 DC Wire
