LUTRON MO-2013 High Precision Milli-Ohm Meter
The LUTRON MO-2013 is a high precision milli-ohm meter designed for professionals who demand accurate and reliable low-resistance measurements. Ideal for electrical inspection, component testing, and quality assurance, the MO-2013 offers fast and stable readings down to 0.1 mΩ, making it a go-to instrument for evaluating electrical connections, windings, and bonding systems.
Features
- 4 terminal devices for accurate measurement of very low resistance.
- Ideal for measuring the resistance of components precisely.
- Ideal for testing protective conductors, lightning conductors and welded points.
- High/Good/Low set-function for input quality control.
- Build in buzzer sound (GOOD STATUS) to assist the Q.C. judgment.
- Especial “CALCULATE” function to measure cable / wire length.
- Wide measuring range, 0.001 m ohm – 20K ohm, 7 ranges.
- RS232/USB computer interface.
- 7 mm large size and back-light LCD display, easy read-out.
- LSI circuit provides high accuracy, reliability and durability.
- Built-in over input protection.
- Durable bench type housing plastic case stand.
Specifications
| Test Range (Test Current) | 20 m ohm (1 A DC) 200 m ohm (1 A DC) 2 ohm (100 mA DC) 20 ohm (10 mA DC) 200 ohm (1 mA DC) 2 K ohm (100 uA DC) 20 K ohm (10 uA DC) |
| Warning Setup | *Warning LCD Indicator *Buzzer |
| Operating Temperature | 0°C to 50°C ( 32°F to 122°C ) |
| Operating Humidity | Less than 80% RH. |
| Power Supply | AC 110V +/- 15%, 50/60 Hz, or AC 230V +/- 15%, 50/60 Hz |
| Power Consumption | AC 110V: Approx. 33 mA AC 230V: Approx. 15 mA |
| Fuse for Power Supply | *500 mA / 250 V *Size: 5 x 20 mm dia.. |
| Data Output | RS 232/USB PC serial interface. *Connect the optional RS232 cable UPCB-02 will get the RS232 plug. *Connect the optional USB cable USB-01 will get the USB plug. |
| Dimension | 280 x 210 x 90 mm (11.0 x 8.3 x 3.5 inch) |
| Weight | Approx. 2.04 Kg (4.49 LB). |
| Standard Accessories | *Power Cord………………………….1 PC. *4 wire with 2 Kelvin clips………..1 pair. *Instruction Manual………………..1 PC. |
| Optional Accessories | *RS232 cable, UPCB-02 *USB cable, USB-01 *Data Acquisition software, SW-U801-WIN |
