Deskripsi
Hytera S1 Pro Business Two-way Radio
Hytera S1 Pro/S1 Pro LF is an exquisite business-ready digital radio for luxury hotel, golf course, club, and more high-end businesses. Sleek and light, the radio strikes the perfect balance between elegance and performance, ready for you to instantly connect your team at the push of a button. Getting the best of two worlds—digital and analog, the S1 Pro/S1 Pro LF levels up your communication experience with a basket of innovative features, including noise cancellation, private call, whisper mode, and voice notification. It gives your business the competitive edge at all time.
Features
Classical Doric Style
- Hytera draws inspiration from the design of the ancient Greek Doric order, and combines the characteristics of elegance, symmetry and scale to inject a unique artistic style into the S1 Pro/S1 Pro LF.
HD OLED Display
- The HD OLED display shows you battery level, frequency, status, channel, and more. Plus, you can create your own channel and radio names that are easy to remember and distinguish.
Reliable Communication
- As a digital radio, S1 Pro/S1 Pro LF is compatible with the existing radios and systems. Lower power consumption, wider communication range, more accurate data transmission.
Privacy Protected
- Only those with the same password can join the group call. Protect the conversation against interference from neighboring groups.
AI-based Noise Cancellation
- Filter out up to 30 dB of noise thanks to the professional AI-based noise cancellation. Your focus is protected. Your productivity improved.
Whisper Mode
- Whisper on a call and still be heard clearly on the other end. Protect your privacy, without disturbing the peace of customers around you.
Outlast Your Shift
- With a battery life of up to 19 hours (0.5W) or 16 hours (3W) of working time and 360 hours of standby time, your focus remains on the job, not the clock.
AirClone
- You can clone configuration data from one S1 Pro to many. All done in a flash.
Hytera Radio APP
- Manage your radio with a phone, at your fingertips. Perform programming, batch configuration, frequency information backup, and then some.
Specification
| General | |
| Model | HYT-S35/HYT-S35 LF |
| Frequency Range | 400-470 MHz (Main Unit)/446 MHz |
| Channel Capacity | 256 |
| Zone Capacity | 6 (Digital + Analog) |
| Channel Spacing | 12.5kHz/20kHz/25kHz |
| Operating Voltage | 3.8V (Rated) |
| Battery | 2200mAh Li-Polymer |
| Battery Life (5/5/90 Duty Cycle, TX Power) | 15hrs (3W) /22hrs (1W) /27hrs (0.5W) |
| Frequency Stability | ±0.5ppm |
| Antenna Impedance | 50Ω |
| Dimensions(H×W×D) mm | 108*53*20mm (Without antenna) |
| Weight | 145g (With belt clip) ;135g (Without belt clip) |
| Display | 1.3 inch OLED |
| Receiver | |
| Sensitivity (Analog) | 0.18μV (12dB SINAD) |
| Sensitivity (Digital) | 0.18μV |
| Adjacent Channel Selectivity | ETSI: 60dB@12.5kHz/70dB@20/25kHz |
| Intermodulation | ETSI: 65dB@12.5/20/25kHz |
| Spurious Response Rejection | ETSI: 70dB@12.5/20/25kHz |
| Blocking | ETSI: 84dB |
| Hum & Noise | 40dB@12.5kHz; 43dB@20kHz; 45dB@25kHz |
| Rated Audio Power Output | 0.5W |
| Rated Audio Distortion | ≤5% |
| Audio Response | +1~-3dB |
| Conducted Spurious Emission | <-57dBm |
| Transmitter | |
| RF Power Output | 400-470MHz: 1W/2W/3W (low/medium/high) |
| FM Modulation | 11K0F3E@12.5kHz; 14K0F3E@20kHz; 16K0F3E@25kHz; |
| Conducted/Radiated Emission | -36dBm＜1GHz; -30dBm＞1GHz |
| Modulation Limiting | ±2.5kHz@12.5kHz; ±4.0kHz@20kHz; ±5.0kHz@25kHz |
| FM Hum & Noise | 40dB@12.5kHz; 43dB@20kHz; 45dB@25kHz |
| Adjacent Channel Power | 60dB@12.5kHz; 70dB@20/25kHz |
| Audio Distortion | ≤3% |
| Environment | |
| Operating Temperature | 0°C ~ +55°C |
| Storage Temperature | -30°C ~ +70°C |
| ESD | ±4kV (Contact) ±8kV (Air) |
