Specifications
| General Data | |
| Frequency Range | 350 – 400 MHz / 380 – 430 MHz 410 – 470 MHz / 806 – 870 MHz |
| Dimensions (H × W × D) | 127.5 × 54.5 × 35.5 mm |
| Weight (without battery, without antenna) | 237 g |
| Operating Voltage | 7.4V |
| Battery (Lithium-ion-battery) | 1800 mAh (standard battery) 2500 mAh (opt. high-capacity battery) |
| Battery Service Live (Lithium-ion-battery) (5-5-90 duty cycle) | > 16 hours (standard battery) > 22 hours (opt. high-capacity battery) |
| LCD Display | 160 × 128 pixels, 65,000 colours |
| Call Groups (TMO) | 2048 |
| Call Groups (DMO) | 1024 |
| Telephone Book | 1000 entries |
| Group Lists (used for scanning, scan lists) | 64 (200 groups per list) |
| Standard Accessories | • Antenna (GPS Integrated) • Lithium-ion Battery 1800mAh (BL180S) • Power Adapter (country-specific) • Dual Charging Station (CH10L13) • Belt Clip (BC12) • Hand Strap (RO04) |
| Ambient Data | |
| Operating Temperature Range | -25°C to +65°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | ETS 300 019 (95%) |
| Protection Against Dust and Moisture | IEC60529 IP67 |
| Shock and Vibration Resistance | MIL-STD-810 C/D/E/F/G |
| Radio Characteristics | |
| Channel Spacing | 25 kHz |
| Transmitting Power | maximally 3 W (settable) / max. 1,8 W at 806 – 870 MHz |
| Receiver Class | ETSI EN 392-2 / 396-2 class A |
| Static Receiver Sensitivity | -112 dBm (typical -116 dBm) |
| Dynamic Receiver Sensitivity | -103 dBm (typical -105 dBm) |
| GPS | |
| Sensitivity | ≤ -138 dBm receiving sensitivity; ≤ -154 dBm signal tracking sensitivity |
| Time to First Fix (TTFF) Cold Start | < 50 seconds |
| Time to First Fix (TTFF) Warm Start | < 10 seconds |
All technical indications were tested according to the corresponding standards. Subject to change on the basis of continuous development.
