FiberFox MINI 12R+ Ribbon Alignment Splicer
The Smallest Splices Both Ribbon and Single Fiber
Features
- Compact and Lightweight: The MINI 12R+ is designed to be highly portable, making it easy to carry and use in various field environments. Its small size and light weight are advantageous when working in confined spaces or needing to move frequently.
- Ribbon Fiber Compatibility: This splicer is specifically designed for splicing ribbon fiber cables, supporting up to 12 fibers at once. This significantly increases splicing efficiency compared to splicing individual fibers.
- Fast Splicing and Heating: The MINI 12R+ boasts a fast splicing time, typically around 15 seconds for single-mode fiber and 20 seconds for heating. This helps to improve productivity, especially when working on large splicing projects.
- User-Friendly Interface: The splicer features a user-friendly interface with a full touch screen, making it easy to operate and navigate through the menus. This simplifies the splicing process and reduces the learning curve.
- Durable Construction: The MINI 12R+ is built to withstand the rigors of field work. Its rugged construction ensures reliability even in harsh conditions.
- Long Battery Life: The splicer comes with two battery packs, which can provide a good number of splicing and heating cycles on a single charge. This ensures that you can work for extended periods without needing to recharge or replace the batteries.
- Comprehensive Kit: The FiberFox MINI 12R+ typically comes as a complete kit, including essential accessories such as a precision cleaver, thermal stripper, splice sleeves, electrodes, and a carrying case.
Specifications
| Applicable Fibers | SMF (G.652/657), MMF (G.651), DSF (G.653), NZDSF (G.655) |
| Fiber Count | Single to 12 Ribbon Fiber |
| Cladding/Sheath Dia. | Single: 125 / 160 to 30mm by Fiber Holder System Ribbon: 125 / Ribbon Fibre Thickness 0.25 to 0.4mm |
| Cleave Length | 10 – 13mm |
| Splice/Heating Mode | 70+ Splice / 30 Heating Modes |
| Typical Splice Loss | 0.05dB (SM), 0.02dB (MM), 0.08dB (DS), 0.08 (NZDS) and 0.05dB (G.657) Measured by cut – back method relevant ITU-T and IEC standards |
| Splice/Tube Heating Time | Typical 18 Sec./Typical 25 Sec. |
| Splice Result | Last 5,000 Splices |
| Viewing Methods/Magnification | 2 Axis CMOS Camera with 4.3” Colour LCD / 33X and 60X Magnification |
| Applicable Protection Sleeve | 60MM, 40MM |
| No. of Splice/Heating per Battery | Typical 110 cycles / single battery (2 Batteries Standard) |
| Electrode Life | 3,000 splices |
| LCD Screen | 4.3” Colour Super Clear Touch Screen with Temper Proof Glass |
| Optical System | No Mirror Type (LED*2) |
| Illumination | RED LED*2 |
| Size/Weight | 122 x 124 x 138 / 1.39kg without Battery |
| Operating Environment | Elevation 0 to 5000 meters, -10°C to 50°C, 0 to 95% Humidity |
| Storage Condition | Temperature -20 to 60°C, 0 to 95% Relative Humidity, Battery -20 to 40°C |
| Pull Test | 1.96 to 2.25N (Standard) |
| Terminals | USB 2.0 (Mini-B Type) Connector for PC Communication |
| Standard Package | •MiniSeries Splicer •Precision Cleaver w/ Auto Bin & Soft Case •Extra Precision Cleaver •Thermal Stripper (includes AC Adapter, Brush) •Two Battery Packs •Fiber Holder (3pr-12f, 250, 900) •Cooling Tray •FOX-SOC Holder •FOX-SOC Holder2/3 •SL40R-50 Splice Sleeves •”One Tap” Cleaning Fluid •Lint Free Wipes (50) •Splice Tray Holder •Lint Free Swabs (100) •5x Magnifier with LED Light •V-Groove Cleaning Pen •Anti-Static Brush •Sweeper Brush •SOC Heater Block •Spare Electrodes (pair) •Car Charger •USB Firmware Update Cable •Three-Hole Stripper •Phillips Screwdriver •Power Cord/AC Adapter •Soft Cover User Manual/CD •Yellow Hard Case w/ Shoulder Strap |
