Deskripsi
BlueSky OMNI Directional Fiberglass Antenna Series
Repeater Antenna Heavy Duty Series
Broad Bandwidth VHF/UHF
Model Number :
- BS – 15060 (150 – 160MHz)
- BS – 16070 (160 – 170MHz)
- BS – 16474 (164 – 174MHz)
- BS – 35065 (350 – 365MHz)
- BS – 36075 (360 – 375MHz)
- BS – 37085 (370 – 385MHz)
- BS – 38095 (380 – 395MHz)
- BS – 39005 (390 – 405MHz)
- BS – 43045 (430 – 445MHz)
- BS – 44055 (440 – 455MHz)
- BS – 45570 (455 – 470MHz)
Specification
| Freq. Range | 150 – 470MHz | |||
|
GAIN Antenna |
Length |
Weight |
Total Weight | |
| 150 – 174 MHz VHF |
9.15 dBi or 7 dBd |
5.07m |
5kg |
12kg |
|
11.15 dBi or 9 dBd |
6.07m |
9kg |
15kg |
|
| 350 – 470 MHz UHF |
11.15 dBi or 9 dBd |
5.07m |
5kg |
12kg |
|
14.15 dBi or 12 dbd |
6.07m |
9kg |
15kg |
|
| Bandwidth VHF | 10 MHz | |||
| Bandwidth UHF | 15 MHz | |||
| V.S.W.R | < 1.5 : 1 | |||
| Connector | N Female | |||
| Maximum Power | 300 Watt | |||
| Impedance | 50 Ohms | |||
| Polarization | Vertical | |||
| Pattern | Omnidirectional | |||
| Colour | White & Blue | |||
