ALINCO DJ-MX1 Submersible VHF Marine Transceiver
The ALINCO DJ-MX1 Submersible VHF Marine Transceiver is a rugged, high-performance device designed specifically for marine applications. Whether you’re a professional or recreational sailor, this transceiver provides crystal clear communications, even in the toughest conditions.
Features
- Ready to sail, antenna, Li-Ion battery pack and rapid charger are all standard
- Operates up to 8 hours without recharging
- International, US and Canadian channels pre-programmed
- Submersible 1m for 30 minutes (IPX7)
- Floats in water even with supplied accessories and lets you know where it is with a flashing red LED light
- 5 Watts output, 1W switchable
- Highly legible display with automatic back light
- Weather channel alert, Channel & Priority Scanning, Dual / Tri -Watch, Call channel and more
Specifications
General |
|
Frequency Range | TX: 156.025 – 157.425MHz RX: 156.050 – 163.275MHz |
Frequency Stability | ±10ppm |
Emission Type | FM (16K0G3E) |
Antenna Impedance | 50Ω |
Rated Voltage | 7.2V (battery) |
Current Consumption | 0.35A (Max. Audio Output) 1.5A (TX/5W)/0.9A (TX/1W) (Battery life up to 8 hours with TX5/RX5/Stand-by 90 cycles) |
Operating Temperature | -20°C to +60°C |
Ingress Protection | IPX7 |
Dimensions | 63 (W) x 138 (H) x 43 (D) mm |
Weight | Approx. 288g include battery, antenna and clip |
Transmitter |
|
RF Output Power | 5W/1W |
Modulation Type | Variable Reactance |
Spurious Emissions | ≥68dB |
Frequency Deviation | ±5kHz |
Receiver |
|
Circuit | Double Conversion Superheterodyne |
Intermediate Frequencies | 1st: 21.7MHz 2nd: 450kHz |
Sensitivity | 0.22µV (12 SINAD) |
Adjacent Channel Selectivity | 70dB |
Intermodulation Response | 68dB |
Audio Output | 0.5W (8Ω 10% THD) |
Standard Accessories | -Battery Pack 7.4V/1200mAh (EBP-104) -AC Adapter 220V (EDC-298) -Rapid Stand Charger (ECD-294) -Whip Antenna (EA-257) -Belt Clip (EBC-54) |
